FNIRSI 1013D Digital Tablet Oscilloscope Dual Channel 100M Bandwidth 1GS Sampling Rate 7 Inches Mini Tablet Digital Oscilloscope

Rs.40,320
SKU: 1013D
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description
The FNIRSI-1013D is a dual-channel oscilloscope designed for R&D and maintenance, offering a 1GSa/s real-time sampling rate and 100MHz bandwidth per channel. It supports various trigger modes (single/normal/auto) and can handle up to 400V with built-in high-voltage protection. The 7-inch 800x480 touchscreen provides easy control with one-key AUTO function for quick waveform display.
It includes convenient features like cursor measurements, peak detection, and built-in 1GB storage for up to 1000 screenshots and waveforms. The oscilloscope also supports USB connectivity for data sharing, and its 6000mAh battery lasts up to 4 hours on a single charge, usable even while charging.


FNIRSI 1013D Digital Tablet Oscilloscope Dual Channel 100M Bandwidth 1GS Sampling Rate 7 Inches Mini Tablet Digital Oscilloscope Features:

  • 2 Channels
  • Portable Handheld Tablet Oscilloscope
  • 1GSa/s Sampling Rate (1X=5MHz,10X=100MHz)
  • 100MHZ * 2analog bandwidth
  • 7" TFT LCD Touch Screen
  • Complete trigger function (single/normal/automatic).
  • One-button AUTO and adaptive trigger (25%, 50%, 75%).
  • Versatile usage for both periodic analog and aperiodic digital signals.
  • high-voltage protection module.
  • 1X can measure 0~40V, 10X can measure 0~400V,100X can measure 0~4000V
  • Powerful Waveform Picture Manager.
  • One-key Screenshot and Saving.
  • Cursor measurement function.
  • Powerful Waveform Picture Manager.
  • Lissajous Graphic Display & FFT Viewing.
  • USB Picture Export
  • Ideal for both periodic analog and aperiodic digital signals.
  • 6000mah battery, continuous usage for 4 hours
  • Targeting the maintenance industry and the research and development industry.

Specifications:

Brand:  FNIRSI
Model:  1013D
Channels:  2
Display:  7 inch 800*480 Pixels
Bandwidth:  100MHz
Sampling Rate:  1GSa/s
Rise Time:  <3nS
Storage Depth:  240 Kbit
Timebase: 50S~10ns
Vertical Sensitivity:  50mV-500V
Input Resistance:  1MΩ
Trigger Mode:  Single / Normal / Auto
Trigger Edge:  Rising / Falling
Coupling:  AC/DC
Highest Test Voltage:  1X:40V 10X:400V
Cursor:  Position XY / Trigger Y
Roll Mode:  Support
One-Button AUTO:  Support
Waveform Manager:  Support (1000 Pic + 1000 Waveform)
Voltage Accuracy:  ±2%
Frequency Precision:  ±0.01% High Precision
Parameter:  12 Kinds in Total
Power Supply:  6000mah Lithium Battery
Standby:  4 Hours
Extension:  USB Export
Charging:  Type-C 5V 2A/3A/4A
