The GT-511C3 FPS (fingerprint scanner) is a small embedded module that consists of an optical sensor mounted on a small circuit board. The optical sensor scans a fingerprint and the microcontroller and software provide the functionality of the module which automatically processes the scanned fingerprint. The GT511C3 Optical Fingerprint Scanner Module with JST SH Connector is a high-performance fingerprint scanner. This optical sensor module is designed for easy integration into applications with serial interface (UART). The GT-511C3 is a TTL fingerprint scanner and can be accessed by Raspberry Pi, Arduino, or any other Microcontroller using just two wires viz Tx & Rx.GT-511C3 Fingerprint Scanner module has an onboard optical sensor and a 32-bit CPU. It does most of the heavy work like reading and identifying fingerprints. A simple set of commands has to be sent from your micro-controller and the GT-511C3 fingerprint scanner does the rest of the work. To get started, just register each fingerprint that you want to store by sending the corresponding command and pressing your finger against the reader three times. The fingerprint scanner can store different fingerprints and the database of prints can even be downloaded from the unit and distributed to other modules. As well as the fingerprint “template,” the analyzed version of the print, you can also retrieve the image of a fingerprint and even pull raw images from the optical sensor. We need two wires are for TX and RX and two wires for power supply (5V). The module can be used in projects for identifying users, for example allowing access through a door by scanning a finger instead of using a key.
Features Of GT511C3 Optical Fingerprint Scanner Module:
Ultra-thin Optical Sensor. High-accuracy & high-speed fingerprint identification technology. Works well with dry, moist, or rough fingerprints. 200 fingerprints storage. Easy one-touch enrollment. 1: 1 verification, 1: N identification. Reading & writing fingerprint template(s) (i.e. processed data) from/to the device. Downloading the raw bitmap image from the device (catalog fingerprints).
Specifications Of 3D Touch Print-Optical Fingerprint Recognition Embedded Module:
Model: GT-511C3 Operating Voltage: 3.3 to 6 CPU : ARM Cortex M3 Core(Holtek HT 32F2755) Image Size : 202 x 258 Pixel Resolution: 450 DPi Effective Scanning Area(mm) : 20 x 16 Operating Temperature : -20°C ~ +60°C Default Baud Rate: 9600bps Dimensions(mm) : 37 x 17 x 9.5
Attachments And Links:
Package Include:
- 1x Finger Print Scanner 1x connecting Cable
