DM-RS151M metal gear robot servo 0.17 sec/60deg (4.8v) 0.15sec/60deg (6.0v) 13.5kg.cm (4.8v) 15kg.cm (6.0v):metal gear high torque 15kg 360o robot digital servo
Features:
Metal gear servo apply for Robot
High presicion metal gears made by CNC;
Select motor,could compare with import one;
expert and experienced in circuit for many years;
TOP choice on case plastic,and best mold manufacture,
Specifications:
Item No.
DM-RS151M
Voltage:
4.8V ~ 6.0V
Speed:
0.15sec/60deg (4.8v) 0.13sec/60deg (6.0v)
Torque:
13.5kg.cm (4.8v) 15kg.cm (6.0v)
Size:
40.2mmX20.2mmX40.5mm
Weight:
62gram
Motor:
Brushed
Gear Train:
Metal
Ball Bearing:
2BB
Type:
Robot Servo
15kg metal gear di-axis 360o robot digital servo
Metal gear Digital servo
Standard 25T teeth horn servo
Select motor,2BB(Dual ball bearing)
Waterproof,with circle rubber to prevent water
Dead band width: 4usc
Interface: (JR)
Futaba,JR,SANWA,Hitec compatible;
Wire length: 30cm,thicker than normal wire,special for HV servo used.
GW: 70g
Package includes:
each retail Packing Include:
Servo DM-RS151M×1PCS
Accessories:
2 x round servo disc horns
2 x mounting screws
Notes:
rotation : 180 degree ( PWM 500-2500US,servo turn about 165-180degree )
270 degree ( PWM 500-2500US,servo turn about 270degree )
360 degree ( PWM 1500US,servo stop,other PWM servo turn continiuously,when 1000 -1500us,the far to 1500us,servo turn faster,when 1500us -2000us,the far from 1500us,servo turn faster )
