UTG9010C UNI T Digital Function Signal Generator

Rs.0
SKU: UTG9010C
Availability : In Stock Pre order Out of stock
People are viewing this right now

Description

UNI-T UTG 9010C FUNCTION GENERATOR can produce sine, square, triangle, pulse, and sawtooth waveforms, etc. The frequency range of the General signal generator is wide and the highest value can be 10MHz. The DC level and duty ratio of a Multifunctional generator are adjustable. Some other features are VCF, TTL level output, and display of output signal, amplitude, and the frequency at the same time. Sine wave Generator can simply be used as a frequency meter in outside testing. With excellent amplitude and frequency characteristics and the rise time of square waveform≤50nS, the electrical specifications reach an international standard of the same type products. Oscilloscope Generator is exquisite and can be widely used in factories, schools, and R & D institutions.

Features:

  • Waveforms: Sine, Square, Triangle, Pulse, Sawtooth, etc.
  • Amplitude range: 1mVpp to 20Vpp
  • Amplitude accuracy & resolution: ≤±5% (1KHz Triangle 20Vp-p), 0.1mV
  • Frequency range: 1Hz to 10MHz
  • Frequency accuracy & resolution: ≤±1% and 1mHz respectively
  • Output power and Impedance: 2Wp-p and 50Ω respectively
  • Attenuator: 20dB + 40dB
  • Input Impedance: 10kΩ

Technical specifications:

Features Range
Model UTG9010C
Waveforms Sine, Square, Triangle, Ramp, Pulse, TTL etc.
Amplitude
Range (no load) from 1mVpp to 20Vpp
Accuracy ±5>#/b###
Resolultion 0.1mV
Frequency
Range from 1Hz to 10MHz
Accuracy ±1>#/b###
Resolultion 1mHz
Output Power 2Wp-p
Output Impedance 50Ω
Attenuator 20dB + 40dB
DC Offset from -10V to +10V
Display Frequency: 4-digits-LED, Amplitude: 3-digits-LED
Duty Cycle from 10% to 90>#/b###
Distortion of Sine ≤2% (at 1kHz)
Rise time of Square ≤35ns
VCF ≥100:1
Frequency Counter
Frequency Range from 0.2Hz to 10MHz
Amplitude Range from 0.5Vp-p to 5Vp-p
Input Impedance 10kΩ
General Characteristic
Power AC 220V,50Hz
Product Color White and Gray
Product Net Weight 2.5 Kg
Product Size 320mm×240mm×100mm
Standard Accessories BNC to Alligator Clips,Power Cord
Standard Individual Packing Gift Box,English Manual



Package:

  • 1 x UTG9010C UNI T Digital Function Signal Generator
