Digital Clamp Meter 600A Mastech MS2109A

Rs.5,435
SKU: 7019
Availability : In Stock Pre order Out of stock
People are viewing this right now

Description

This Mastech Ms2109A is a portable professional measuring instrument with LCD and backlight for easy reading.  A digital clamp meter MS2101 is Used to measure AC/DC current, voltage, resistance, capacitance, frequency and duty cycle. The  Handheld True RMS clamp Multimeter design for the range switch makes measurement easier. Overload protection and low battery indication are provided. Single Hand  Digital Tong Tester is an ideal multi-functional instrument with scores of practical applications for professional, workshop, school, hobby and home use. Features Of Single Handed True RMS Digital AC/Dc Clamp Ampere Meter MS2109A:

Auto measuring range.
Full measuring range overload protection.
The maximum allowable voltage between measurement end and ground: 600V DC or 600V AC Operational height: maximum 2000m Display: LCD
Displayed maximum value: 5999 digits.
Polarity indication: automatic indication, means negative polarity.
Exceeding measuring range display: '0L'or '-0L'. Sampling rate: about 3 times/s, simulation bar 30 times/s. Unit display: has the function and power unit display.
Auto-off time: 15 min

Specifications Of Mastech MS2109A Portable Professional Auto range AC/DC Current Tong Tester :

DC Voltage:

Range:600mV/6V/60V/600V
Accuracy±(0.7% +2)

AC Voltage:

Range:6V/60V ±(0.8% +3)
Range:600V ±(1.0% +4)

DC Current:

Range:60A/600A
Accuracy:±(3% +6)

AC Current:

Range:60A/600A
Accuracy:±(2.5% +6)

Resistance:

Range:600/6k/60k/600k ohm  ±(0.8% +3)
Range:6M/60M ohm ±(1.2% +3)

Capacitance:

Range:40nF/400nF/4µF/40µF/400µF/4000µF
Accuracy:±(4.0% +5)

Temperature:

Range:-20°C~1000°C

Duty ratio:0.1 - 99.9% ±(3.0%+5)
Dimensions: 8.66 in x 3.15 in x 1.61 in (22 cm x 8 cm x 4.1 cm)
Weight 20.46 oz (580 g)

Package includes:

1x  Digital clamp multimeter 600A Mastech MS2109A
