These 1000A AC/DC digial clamp meters are stable, safe and reliable with low power consumption. Its full range overload protection and unique appearance design make these clamp meters the ideal tool for maintenance and repair of electrical and power lines up to 1000A AC.
Features:
1. 1000A AC/DC current measurement, 3 times/s sampling rate2. Auto/manual ranges selectable
3. Zeroing function
4. LCD backlight
5. Data hold; Duty cycle
6. Auto power off and low battery indication
7. Diode; Continuity buzzer; Input Impedance for DCV
Technical specifications:
Specifications | Range | UT207A |
AC current (A) | 1000A | ±(2%+2) |
DC current (A) | 1000A | ±(1.5%+5) |
AC voltage (V) | 750V | ±(1.2%+3) |
DC voltage (V) | 1000V | ±(0.8%+1) |
Resistance (Ω) | 40MΩ | ±(1%+2) |
Frequency (Hz) | 10MHz | ±(0.1%+3) |
General Characterisitics | ||
Power | 9V battery (6F22) | |
Display | 47mm x 30mm | |
Product color | Red and grey | |
Product net weight | 533g | |
Product size | 286mm x 105mm x 45mm | |
Standard accessories | Battery, test leads, tool box | |
Standard individual packing | Gift box, English manual |
Package:
- 1 x UT207A UNI T Digital Clamp Meter 1000A
