LM2596HV module is a high input voltage version of the LM2596 Module. The LM2596HV module is a DC to DC converter buck converter module with an input voltage range of 4.5 volts to 50 volts and an output of 3 volts to 40 volts. This output is variable and can be varied using the on-board multi-turn potentiometer. Buck Converter Module is capable of driving a load up to 3A with high efficiency. When the output current required is greater than 2.5A(10W) an external heatsink is suggested.Features Of High Voltage DC to Dc Buck Converter Module:
High efficiency up to 92%.
4.5 Volt - 50 Volt adjustable input voltage range.
3 volt - 40 Volts adjustable output voltage range.
With over-current and over-temperature protection, safe for use.
Fine workmanship, long life span.
It can set the float voltage and charging current.
Special design enhanced heating radiating.
Specifications Of LM2596HV Adjustable Step-Down Power Module:
Non-isolated constant voltage module
Rectification: non-synchronous rectification
Input voltage: 4.5V-60V
Output Voltage(Less than input): 1.3V-30V
Output current: 3A maximum
Conversion efficiency: 92% (maximum)
Switching frequency: 52KHz
Output ripple: 50mV (maximum) 20M-bandwidth
Load regulation: ± 0.5%
Voltage regulation: ± 2.5%
Operating temperature: -40 ℃ to +85 ℃
LM2596HV Module datasheet
Package Include:
1 X DC-DC Step Down Buck Module Lm2596HV
