Description
mm x 500mm Linear Rail Shaft Rod with Bearing Guide Support and Bearing Block for CNC applications.
Specifications:
Optical Axis
Material: Stainless steel
Color: Silver
Diameter: 8mm
Total Length: 500mm
Rail Shaft Support
Material: Aluminum
Color: Silver
Hole diameter: 8mm
Total length: 41mm
Height: 32mm
Linear Slide Block
Material: Aluminum
Color: Silver
Bore diameter: 16mm
Hole diameter: 8mm
Total length: 33mm
Height: 21mm
Features:
Good wear resistance and strength, high accuracy, hard to rust.
Has good performances, low friction coefficients and long usage spans.
Suitable for Industrial automation equipment, stepper motor rails, such as 3D printers, engraving machine, XYZ module, slider, lifts etc.
How to install:
- Put Linear Slide Block into the Lead rod.
- Then the Rail Shaft Support separately install at both ends of the Lead screw.
- 3According to the size of you need to adjust the distance between the nut and Mounted ball bearing.
- Put shaft coupling into the Lead screw beside the Mounted ball bearing.
Package Includes:
- 1 X Optical Axis 500mm
- 2 X Aluminum Rail Shaft Support
- 2 X Linear Slide Block
