7s 24v 20a 18650 Lithium Lion Battery Charger Module Protection Board Bms Pcb With Wire

Rs.1,960
SKU: 12338
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

7S 24V 20A Lithium Battery BMS Protection Board with Balancing Function

Features:

  • Protection circuit board is the heart of battery pack, must to have to avoid battery pack from explosion, fire and damage.
  • It will protect battery pack from overcharging, over-discharging over-current and short circuit.
  • With equilibrium function to keep each cell in balance and good service life.
  • This protection board is used for 7 series 24V Lithium batteries, comes with wire.
  • Choosing the correct protection board and applying it appropriately is vital to the longevity your batteries.

Specifications:

  • Size: 90mm*47mm*10mm / 3.54*1.85*0.39"
  • Equalizing Current: 80mA(VCELL=4.20V)
  • Equalizing Point: 4.18±0.03V
  • Overcharge Threshold: 4.3±0.05V
  • Overcharge Time Delay: 75mS
  • Overcharge Release: 4.05±0.05V
  • Over-discharge Threshold: 2.4±0.08V
  • Over-discharge Time Delay: 5mS
  • Over-discharge Release: Disconnect load, and voltage of each battery cell is higher than over-discharge threshold
  • Over-current Threshold: 40A
  • Over-current Release: Disconnect load release
  • Working Current; 20A
  • Quiescent Power Dissipation: <500uA
  • Short Circuit Protection: Yes, disconnect load can self-recovery

Package Includes:

1 x 7S 20A Battery Protection Board
