Nema 34 75mm Stepper Motor is a high torque hybrid bipolar stepping motor with a 3.4×3.4 inch faceplate. Nema 34 75mm Stepper Motor, Hybrid stepper has the combination of the features of the Variable Reluctance Stepper Motor and Permanent Magnet Stepper Motor. This motor has a step angle of 1.8 deg., this means that it has 200 steps per revolution and for every step, it will cover 1.8°. This NEMA 34 is a 2-Phase motor with 4 wires. Compatible controllers for this motor are CW230, CW250 and CW860.
Features of Nema 34 75mm Stepper Motor:
High performance, low price
Supply voltage from 35VDC
Overvoltage, under voltage, overcorrect, phase short circuit protection
Offline command input terminal
Motor torque is related to speed, but not related with step/revolution
High start speed
High holding torque under high speed
Specifications of Nema 34 75mm Stepper Motor:
Body Length: 75mm
Shaft Length: 30mm
Shaft Size: 10mm
Ampere: 6amp
Step Angle Accuracy: ±5%
Resistance Accuracy: ±10%
Inductance Accuracy: ±20%
Temperature Rise: 80℃ Max
Ambient Temperature: -20℃～+50℃
Insulation Resistance: 100MΩMin.500VDC
Dielectric Strength: 500VAC for one minute
Shaft Radial Play: 0.02Max.(450g-load)
Shaft Axial Play: 0.08Max.(450g-load)
Applications:
CNC mills & milling machines.
CNC lathes.
Pick-n-place machines.
Laser Engravers and Laser sCutters.
Vinyl Sign Cutters.
CNC Plasma Cutters.
CNC Foam Cutters.
Package Includes:
1 x Nema 34 75mm Stepper Motor
