Description
The 6N136 is a 1-channel 8-pin high speed Transistor Optocoupler consists of an AlGaAs LED optically coupled to a high speed photodetector transistor for each channel. A separate connection for the bias of the photodiode improves the speed by several orders of magnitude over conventional phototransistor optocoupler by reducing the base-collector capacitance of the input transistor. It is suitable for line receivers, pulse transformer replacement, output interface to CMOS-LSTTL-TTL and wide-bandwidth analogue coupling.
1Mbps High speed
890V Maximum working insulation voltage
6000V High allowable overvoltage
0 to 70°C CTR guaranteed
Applications
Signal Processing, Industrial
6N136 6N136 8 Pin Transistor Optocoupler
Rs.78
