This 42BYGHW804 IM42HS60 NEMA17 Stepper Motor For 3D Printer is High-torque stepper motor in size NEMA 17 (42 mm) with 1.8° step angle (full step) with D-Shaft for easy and reliable connection with coupler. 42BYGHW804 Nema17 steppers are a great way to get things moving, especially when positioning and repeatability is a concern. This is a Bipolar motor.SPECIFICATIONS:
Step Angle: 1.8
Holding Torque: 4.8kg.cm
Rated Voltage: 3.6Volt
Rated Current: 1.2A/Phase
Form Factor: NEMA 17
Shaft Type D-Shaft
Wire Connector JST PH male connector.
2-Phase (4-Wires)
Holding Torque: 48N.cm (4800g-cm)
Resistance: 3.2Ω/phase
Inductance: 5mH/phase
Form factor: NEMA 17
Dimensions:
42 x 42 x 47mm
Weight: 380g
Shaft Diameter: 5mm
Shaft Length: 18mm
4 x M3 Holes for mounting base
Connection
A+
A-
B+
B-
Black
Green
Red
Blue
Package Include:
1x Nema17 Stepper Motor
