Bipolar NPN Transistor is an age-old Japanese Bipolar audio frequency NPN transistor. 2SC945 50V NPN transistor has a decent gain value (hfe) of maximum 700 and is highly linear. Hence this bipolar transistor was widely used in amplifier applications for pre-amplifying purpose, in high-frequency circuits. This NPN junction transistor is also used as oscillators with is complementary A733 PNP transistor.When used as a switch it can easily be controlled by an MCU/MPU since it has a base voltage of only 5V. C945 transistor NPN can switch loads up to 50V but has a very low collector current rating of the only 150mA so this transistor is not really a good choice to be used as a switch. A better alternative for switching applications will be 2N2222.
Features Of 2SC945 Best Bipolar NPN Transistor:
2sc925 well known as C945 NPN transistor.
Max Voltage Collector Emmiter=50 V.
Max Collector current=150 mA.
Collector power dissipation: 400 mW.
Japanese High-frequency amplifier NPN Transistor.
Current Gain (hFE) is 70 to 700 (high linearity).
Continuous Collector current (IC) is 150mA.
Collector-Emitter voltage (VCEO) is 50 V.
Collector-Base voltage (VCB0) is 60V.
Emitter Base Voltage (VBE0) is 5V.
Transition Frequency is 150MHz.
Specifications Of Amplifier High-Frequency OSC NPN Transistor:
Type of transistor: NPN
Polarisation: Bipolar
Collector-Base Breakdown Voltage: 60V
Collector-Emitter Breakdown Voltage: 50V
Collector current: 150mA
Power: 250mW
Case: TO92
Mounting: THT
Frequency: 250MHz
Pin Description:
Emitter: Current Drains out through emitter, normally connected to ground
Collector: Current flows in through collector, normally connected to load
Base: Controls the biasing of the transistor, Used to turn ON or OFF the transistor
Applications:
Low current switches
Pre-amplifiers
H-bridge circuits for low power motors
Audio frequency amplifier circuits
Oscillator circuits
Package Includes:
1 x 2SC945 Bipolar NPN Transistor
