These shrouded, 2-pin JST XH-style male connectors have straight leads and match the female connector on the 2-pin female XH-style cable, and they also work with other many other 0.1″-pitch female connectors, such as our female premium jumper wires. They are sold in packs of four units.The B2B-XH-A(LF)(SN) is a part of XH series with a mounting height of 9.8 mm and it is applicable to PC Board thickness of 1.6 mm. It has an Operating Temperature range of -25° C to +85° C.
Features:
Original folded beam contact
Box-shaped shrouded header
Header with a boss
Interchangeability
Conforming to the HA terminal
Current Rating: 3A AC, DC(AWG #22)
Voltage Rating: 250V AC, DC
Contact Resistance: Initial value/10mΩ max.
Insulation Resistance: 1000 MΩ min
Withstanding voltage: 1000V AC/minute
Applicable wire: AWG #30 to #22
