2.8 Inch Nextion Tft Hmi Lcd Touchscreen Nx3224t028

Rs.3,430
SKU: 7599
Availability : In Stock Pre order Out of stock
People are viewing this right now

Description

2.8 inch Nextion TFT HMI LCD Touchscreen NX3224T028 is a Seamless Human Machine Interface (HMI) solution. 2.8 inch Nextion TFT HMI LCD Touchscreen NX3224T028 that provides a control and visualization interface between a human and a process, machine, application or appliance. Nextion is mainly applied to the Internet of thing (IoT) or the consumer electronics field. It is the best solution to replace the traditional LCD and LED Nixie tube.Nextion includes a hardware part (a series of TFT boards) and a software part (the Nextion editor). The Nextion TFT board uses only one serial port to communicate. It lets users avoid the hassle of wiring. We noticed that most engineers spend much time in application development but get unsatisfactory results. As a solution to this situation, Nextion editor has mass components such as button, text, progress bar, slider, instrument panel etc. to enrich the interface design. Furthermore, the drag-and-drop function ensures that users spend less time in programming, which will reduce 99% of their development workloads. With the help of this WYSIWYG editor, designing a GUI is a piece of cake.
It's easy to adapt Nextion family HMI to existing projects. Users just need to provide it with a UART.
We are also selling Nextion touchscreen in different sizes like 2.4", 3.2", 3.5", 4.3", 7" etc.
Features of 2.8 inch Nextion TFT HMI LCD Touchscreen NX3224T028:

320 x 240 Resolution
RGB 65K true to life colours
TFT screen with integrated resistive touch panel
4 pin TTL serial interface
4M Flash memory for User Application Code and Data
Onboard micro-SD card slot for firmware up-gradation
Visual Area: 57.6mm(L)×43.2mm(W)
Adjustable Brightness: 0~180 nit, the interval of adjustment is 1%
5V65mA power consumption
Compatible with Raspberry Pi A+, B+, Pi 2, Pi 3, Arduino.
Certificates: CE/EMC, RoHS (certificates)

Specifications of 2.8 inch Nextion TFT HMI LCD Touchscreen NX3224T028:

Model No.
NX3224T028

Nextion Type
NX3224T024_011R (R: Resistive touchscreen)

Operating Voltage Range
4.75~7 V

Operating Current
90 mA

Layout Size
74.4 (L)×42.9 (W)×5.8 (H)

Net weight
25g

Touch Type
Resistive

Colours
65K (65536) Colors, 16 bit, 5R6G5B

Recommended Power Supply
5V, 500mA, DC

Working Temperature Range
-20 to 70 ℃

Working Humidity Range
10% to 90% RH

USB Interface
No

Micro-SD Card Slot
Yes (FAT32 format), support maximum 32G Micro SD Card

Flash Memory
4 MB

RAM Memory
3584 BYTE

Documents:
Please visit our wiki page for more information about this product. Any suggestions for improvement, such as correcting errors, adding more demo codes or tutorials, will be highly appreciated.
Technical Support:
For technical support, please open a ticket on Itead Support System.
Package includes:

1 x Nextion NX3224T028 – Generic 2.8″HMI LCD Touch Display
1× power supply test board
1× 4-pin grove cable

Note: There are a small power supply test board and a wire for you to test if the electricity supply is enough or not. Please see below image how to use it.
