2.4 inch Nextion TFT HMI LCD Touchscreen NX3224T024 is a Seamless Human Machine Interface (HMI) solution. 2.4 inch Nextion TFT HMI LCD Touchscreen NX3224T024 that provides a control and visualization interface between a human and a process, machine, application or appliance. Nextion is mainly applied to the Internet of thing (IoT) or the consumer electronics field. It is the best solution to replace the traditional LCD and LED Nixie tube.Nextion includes a hardware part (a series of TFT boards) and a software part (the Nextion editor). The Nextion TFT board uses only one serial port to communicate. It lets users avoid the hassle of wiring. We noticed that most engineers spend much time in application development but get unsatisfactory results. As a solution to this situation, Nextion editor has mass components such as button, text, progress bar, slider, instrument panel etc. to enrich the interface design. Furthermore, the drag-and-drop function ensures that users spend less time in programming, which will reduce 99% of their development workloads. With the help of this WYSIWYG editor, designing a GUI is a piece of cake.
It's easy to adapt Nextion family HMI to existing projects. Users just need to provide it with a UART.
We are also selling Nextion touchscreen in different sizes like 3.2", 3.5", 4.3", 7" etc.
Features of 2.4 inch Nextion TFT HMI LCD Touchscreen NX3224T024:
320 x 240 Resolution
Compatible with Raspberry Pi A+, B+ and Raspberry Pi 2
RGB 65K true to life colours
TFT Screen with integrated 4-wire Resistive Touch Panel
Easy 4 pin interface to any TTL Serial Host
4M Flash memory for User Application Code and Data
Onboard micro-SD card for firmware upgrade
Visual Area:36.72mm(L)×48.96mm(W)
Adjustable Brightness:0~180 nit, the interval of adjustment is 1%
5V90mA power consumption
Generic using for all Arduino or Raspberry Pi project
CE/EMC, RoHS certified (certificates)
Specifications of 2.4 inch Nextion TFT HMI LCD Touchscreen NX3224T024:
Link Wiki
No
Display Resolution
320 * 240
Display Interface
Serial
Screen Type
Touch Screen
Display Controller
No
TFT display interface
N/A
Display Size
2.4”
Board Size
74.4*42.9mm
Expand
SD Card Socket
Touch Screen
Weight
53g
Documents:
Please visit our wiki page for more information about this product. Any suggestions for improvement, such as correcting errors, adding more demo codes or tutorials, will be highly appreciated.
Technical Support:
For technical support, please open a ticket on Itead Support System.
Package includes:
1 X 2.4'' HMI LCD Display Module
1 X 4P Cable
1 X UB to 4pin connector
Note: There are a small power supply test board and a wire for you to test if the electricity supply is enough or not. Please see below image how to use it.
