12x12x7.5mm Tactile Push Button Switch is used as general-purpose PCB tactile pushbutton. Tactile Push Button Switch colour may differ from the image. This is a standard 12mm square momentary button. What we really like is the large button head and good tactile feel (it ‘clicks’ really well). This button is great for user input on a PCB or a good, big reset button on a breadboard. Breadboard friendly!Features of 12x12x7.5mm Tactile Push Button Switch:
NO (Normally Open) contacts.
Good snap action feels with an audible click.
4-terminal, these switches are 4-terminal normally open pushbuttons. Pins are formed solder type on 5.08mm (0.2″) centres on one side x 12.7mm (0.5″) and are breadboard friendly.
Breadboard friendly.
The 4-pin layout works well in solderless breadboards or perf boards.
Specifications of 12x12x7.5mm Tactile Push Button Switch:
Main Colour
Black, Silver Tone
Product Name
Tactile Switch
Net Weight
10g
Country of Manufacture
CHINA
Switch Size
12x12x7.5mm
Material
Plastic, Metal, Electric Part
Withstand Voltage
50Hz/min
Rated current
50mA 12VDC
Contact resistance
30mΩ max
Insulation resistance
100mΩ min
Operating temperature
-30 to + 70
Operating Force
100~350g
Life
100000times
Package Includes:
1 x 12x12x7.5mm Tactile Push Button Switch
