12 volt DC Power Supply with a load Capacity of 20 Amp or 240 Watt:SP-240-12 is a 240W 12V 20A enclosed industrial style power supply offering full range AC input and active PFC. The built-in DC fan allows the SP-240-12 to operate within temperatures of -20°C to +70°C and the built-in protections offer added assurances over the quality and reliability of the unit
Technical Specifications:
Manual Switch between 110V and 220V Input.
+ / - 10% adjustable output voltage.
AC input: 90-130V; 180-265V.
DC Output: DC 12V , 0 ~ 20A.
Auto on/off cooling fan.
High Efficiency, Low Temperature.
High reliability.
LED indicator for power on
Built-in EMI Filter.
Over Load and Short Circuit Protection.
Over Voltage Protection.
Auto-recovery after protection.
Wiring:
● L, N, GND: AC power input
● +V: DC power output "+"
● -V: DC power output "-"
● +V / ADJ: fine adjustment of output voltage
Working Temperature: 0~40℃
Humidity: 0~95% Non-Condensation
