NEW, UNUSED, fresh out of the box. In electronics and electrical engineering, a fuse is an electrical safety device that operates to provide overcurrent protection of an electrical circuit. Its essential component is a metal wire or strip that melts when too much current flows through it, thereby interrupting the current.
Cartridge fuses are used to protect motors and branch circuits where higher amps or volt ratings are required. General Purpose fuses have no time-delay and protect fuse panels, appliances, and branch circuits.
Specifications:
Attribute
Value
Current Rating
10 A
Voltage Rating
250 V ac
Fuse Speed
F
Fuse Size
6 x 30mm
Diameter
6mm
Overall Length
30mm
Body Material
Glass
Breaking Capacity at Maximum Voltage Rating
100 A @ 250 V ac
Series
FSF 5x20
Maximum Operating Temperature
+125°C
Minimum Operating Temperature
-55°C
Typical Application:
Cartridge fuses are a relatively cheap way of protecting electrical equipment from short circuits and overcurrent and can be used to protect electrical appliances such as motors air-conditions, refrigerator, pumps, etc. They can be found in the following areas:
Industrial
Commercial
Home/Residential
Automotive
